Fluke FLK-IRR1-SOL Solar Irradiance Meter

Send Inquiry

Request To Call Back

Fluke FLK-IRR1-SOL Solar Irradiance Meter

Name: Fluke FLK-IRR1-SOL Solar Irradiance Meter
Brand: ALICO INDUSTRIAL EQUIPMENTS
Price: 34999.0 INR
Availability: InStock

Price 34999.0 INR/ Piece

Get a Price/Quote

MOQ : -2 Piece

Fluke FLK-IRR1-SOL Solar Irradiance Meter Specification

Features
Built-in compass, tilt sensor, temperature and irradiance measurement, instant solar radiation readings, wireless data logging via Fluke Connect app

Equipment Type
Solar Irradiance Meter

Resolution
1 W/m2

Humidity
0 % to 85 % Relative Humidity (Non-Condensing)

Test Range
0 to 1400 W/m2

Interface Type
Bluetooth LE

Temperature
-20C to 60C (Operating)

Max Height
174 mm

Measuring Range
0 to 1400 W/m2

Display Type
Backlit Digital LCD

Power Supply
3 AA Batteries

Response Time
500 ms

Application
Solar Panel Installation and Maintenance

Automation Grade
Manual

Accuracy
(3 % + 10 digits)

Mounting Type
Handheld

Operating Voltage
4.5 V DC (3 AA Batteries)

Usage
Instantaneous measurement of solar irradiance and panel alignment

Machine Weight
250 g

Control Mode
Manual

Storage Temperature
-30C to 60C

Dimensions
174 mm x 93 mm x 49 mm

Altitude
Up to 2000 m

Tilt Sensor Accuracy
3

Battery Life
Up to 100 hours

Data Logging
Up to 99 records

Model Number
FLK-IRR1-SOL

Environmental Protection
IP40

Compass Accuracy
7

Fluke FLK-IRR1-SOL Solar Irradiance Meter Trade Information

Delivery Time
2 Days

About Fluke FLK-IRR1-SOL Solar Irradiance Meter

Description

Measure solar irradiance, ambient and PV module temperature, array orientation and tilt angles
Make instantaneous measurements to determine the watts per square meter solar irradiation, required by IEC 62446-1 standard
High contrast LCD with large numbers for easy readability in direct sunlight
Includes convenient carry case with shoulder strap

Instant and Accurate Solar Measurements

With the FLK-IRR1-SOL Solar Irradiance Meter, you can instantly measure solar irradiance, panel tilt angle, compass direction, and temperature. Its high-speed response time (500 ms) and resolution (1 W/m2) enable precise analysis of solar energy potential and panel alignment on-site, significantly improving installation efficiency and maintenance accuracy.

Wireless Data Management and Smart Connectivity

Leverage built-in Bluetooth LE to transfer and log up to 99 measurement records via the Fluke Connect app. This feature streamlines reporting and analysis, allowing technicians to track data trends and maintain comprehensive installation or maintenance reports wirelessly, reducing manual errors and improving workflow productivity.

Rugged Design for Diverse Environments

Engineered for professional use, the FLK-IRR1-SOL thrives in operating temperatures from -20C to 60C, with storage tolerance down to -30C. Its IP40 rating, 85% non-condensing humidity range, and altitude capacity up to 2000 meters ensure reliable performance in varying field environments. Lightweight and handheld, it's tailored for portability and endurance.

FAQ's of Fluke FLK-IRR1-SOL Solar Irradiance Meter:

Q: How do I use the Fluke FLK-IRR1-SOL to measure solar irradiance on a panel?

A: Simply position the FLK-IRR1-SOL on the surface of your solar panel and press the measurement button. The backlit digital LCD provides instant readings of solar irradiance, panel temperature, compass direction, and tilt angle for precise alignment and site assessment.

Q: What are the benefits of using this irradiance meter for solar panel installation?

A: The FLK-IRR1-SOL ensures accurate alignment of panels for peak performance, offers fast response time, logs crucial data wirelessly, and reduces errors by providing essential information such as irradiance, tilt, and orientation on-the-spot.

Q: When should I utilize the FLK-IRR1-SOL during solar projects?

A: Use this meter during site surveys, installation processes, routine system checks, and troubleshooting to ensure panels are optimally positioned and performing as expected. Its instant readings make it useful at multiple project stages.

Q: Where can I store data collected during measurements?

A: Measurement data can be logged directly on the FLK-IRR1-SOL, with the ability to store up to 99 records. Additionally, you can wirelessly transfer data to the Fluke Connect app for detailed analysis and long-term storage.

Q: What is the operating process for data logging with this device?

A: Activate Bluetooth LE, pair the meter with the Fluke Connect app, and select the data logging function. As you measure, records are wirelessly sent to your smart device, supporting streamlined documentation and reporting in the field.

Q: How accurate are the measurements and under what conditions should the device be used?

A: The FLK-IRR1-SOL offers an accuracy of 3% plus 10 digits, with optimal operation between -20C to 60C and up to 85% relative humidity. It's designed for use up to 2000 m altitude, and its robust build ensures stability in most installation environments.

Q: What battery life can I expect, and how is the device powered?

A: Powered by three AA batteries, the FLK-IRR1-SOL offers up to 100 hours of continuous use, supporting long field sessions without frequent battery replacement.
